Intelligence Storm
An educational robot that brings together programming, artificial intelligence and robot competitions. Designed for students from upper primary to junior secondary, it combines a powerful processor, many sensors and basic AI algorithms.
A powerful brain
Students learn programming and introductory AI through project-based lessons.
2.4″ touchscreen
High-definition colour LCD touchscreen for easy control.
Ports
8 sensor ports and 4 motor ports, plus built-in Bluetooth.
Easy to build
34 pin holes make it simple to mount in a robot.
Built-in audio
An extra 16 MB MP3 player is built in, with a built-in lithium battery.
Motors and sensors
Large motor
High torque with a built-in encoder, and a good-looking shape that is easy to build with.
Medium motor
Detected automatically, with servo function, single-axis output and high speed.
AI vision module
Python programming, voice recognition, image learning and visual recognition.
Ultrasonic sensor
Full-colour LED, strong resistance to interference, accurate and long range.
Photoelectric sensor
Continuous signal, fast response, adjustable threshold and sunlight resistance.
Colour sensor
Raw RGB output, recognition of 6 basic colours, adaptive brightness and auto white balance.
Touch sensor
Photoelectric switch with high sensitivity, a status indicator and long life.
Light module
Shows seven colours with a soft three-colour glow, fast switching and low power use.
Optional expansion sensors
Add more abilities to the robot with these extra modules.
Smart eye & light ring
Smart eye and a full-colour light ring.
Infrared
Infrared receiver, transmitter and detector. Infrared distance sensor measures up to 20 cm in 10 levels.
Gyroscope
Six-axis attitude data with automatic calibration.
Magnetic sensor
High sensitivity, analogue signal and resistance to mechanical stress.
Barometer
Pressure range 300–1100 hPa, with temperature and height resolution.
Laser distance sensor
Measures 2–120 cm with 1 cm accuracy.
Gesture sensor
Contactless detection of 8 gestures.
Temperature & humidity
-40 to 125 °C and 0–100% RH.
Dot-matrix display
Adjustable brightness and custom patterns, with fast refresh.
Scanning camera
Reads QR codes and barcodes from up to 18 cm.
Small servo
0–270° movement, 1° positioning accuracy and metal gears.
Bluetooth
Bluetooth 4.2 adapter and a Bluetooth gamepad for remote control.
Program on PC, tablet or phone
The set provides a strong AI teaching platform with Scratch 3.0 block programming, flowchart programming, and Python and C code programming. It runs on PCs, tablets and phones.
The phone app also supports camera AI, face recognition and AR QR codes.
88 brick types, 620 parts
Made from quality materials with careful production control. The bricks have a neat finish, precise structure and a smooth, soft fit.
They support 10 mm hole pitch and screw-free building.
Sample builds
Two stages, 64 lessons
The set comes with two stages of lessons (64 in total), plus 32 extension lessons. Students learn how robots work, how to read sensors, motor control, logic and variables. AI modules introduce vision and voice recognition. Teaching slides, lesson plans, demo videos and building manuals are provided.
Light world
Hello World, running lights, flashlight, traffic light
Vehicles
Gear shifting, train, helicopter, siren police car
Smart life
Electric gripper, automatic door, obstacle-avoiding robot, anti-fall robot
Industry
Lift door, forklift, synchronised control, mechanical hand
Fun games
Fire-line maze, lottery machine, bumper car, toy remote car
Smart living
Spinning bike, safe, vacuum cleaner, sound meter
Sports
Runner, push-up robot, basketball machine, ski robot
Music
Smart speaker, ultrasonic guitar, rotating music box, dancing robot
Animals and vehicles
Obstacle scorpion, night beetle, matador, hexapod robot, clockwork car, transforming robot
Sound and light
Voice-controlled toy, light-chasing car, telegraph
AI applications
Voice control, danger-detecting car, self-driving, gesture fan, traffic signs, tag recognition, face tracking, ball tracking
Specifications
Bring AI robotics to your students
Talk to us about school packages, training and quotations.
